Description
Press & Print Width: 13 inch (330 mm) max web width, 7 inch (178 mm) min web width
(4.5 inch (114 mm) min web width roll-to-roll), 12.5 inch (318 mm) digital print width
13 inch (330 mm) flexographic print width
Substrates: Pressure sensitive stock (paper, BOPP,PET, PP), unsupported paper, tag stocks; no priming required
Thickness: 60 - 250 micron, .0023 inch (.06 mm) min, .010 inch (.25 mm) max
Digital Image Resolution:1200 x 1200 dpi native
Flexo Repeat Range:7 - 18 inch (178 - 457 mm) / 47 inch (1195 mm) banner mode
Die Repeat: 8.5 inch (216 mm) min / 18 inch (457 mm) max
Printing Speed: 44 fpm (13.5 mpm), 62 fpm (18.9 mpm)
Digital Front End & RIP: Print driver accepts pdf files from your in-house or external pre-press operation
Color Management: 4 color process CMYK, hybrid spot with in-line flexo
Curing & Drying: Air cooled UV LED
Unwind Capacity: 30 inch (762 mm), core size: 3 inch (76 mm)
Rewind Capacity: Dual, max 16 inch (406 mm), Single, max 18 inch (457), core size: 3 inch (76 mm)
Control Software: Proprietary
Die Tooling Compatibility: Mark Andy and most other rotary die tooling with purchased adapters
Installation Footprint: W x D x H: 140 x 40 x 60 inch / (3,556 x 1,016 x 1,524 mm)
Environment: Power: 220 volts, 50/60 Hz, 90 amps, single phase, Temperature: min 50F (10c) - max 86F (30c)
Optimum Temperature: 64F (18c) - 74F (23c), Relative Humidity: min 10% - max 80%, Optimum Humidity: 40% - 60%
